Technical data
LINEAR AXES | ||
X axis stroke | mm | 3000-4000 |
Y axis stroke | mm | 1800-2550 |
Z axis stroke | mm | 700 |
X-Y-Z axes speed | m/min | 90-90-60 |
WORKTABLES | Bars worktable – Beam worktable | |
MACHINING HEAD UNITS | IX24-IX34 | |
Rotation speed max. | rpm | 24000 |
ROTATING AXES | ||
B rotation | ° | 360 in continuous |
C rotation | ° | +/- 370 |
