Description
Technical data
|
Max working speed
|
m/min
|
25 (30 opt)
|
|
Coil edge thickness
|
mm
|
0.3-3
|
|
Pre-cut strip thickness
|
mm
|
0.4-1
|
|
Solid wood thickness
|
mm
|
25
|
|
Panel thickness
|
mm
|
10 – 60 (80 opt)
|
|
PANEL DIMENSIONS WITH COIL EDGE
|
|
|
|
Min/max panel length
|
mm
|
135 (125 opt)-3200
|
|
Min/max panel width
|
mm
|
95 (55 opt)-1200
|
|
Pneumatic system
|
MPa
|
6
|
|
Technology for edge application
|
|
EVA, PUR, EVA+PUR
AirFusion+
SLIM LINE
|
|
TYPE OF EDGE
|
EXAMPLE OF APPLICATION
|
MAX THICKNESS
|
|
Paper
|
Raw / prepainted
|
0,6 mm
|
|
Plastic in coil
|
ABS, PVC, PP (with/without film)
PMMA (polished or rough to polish/smooth)
|
3 mm
|
|
Alluminium
|
Shine/ Satin
|
3 mm
|
|
Pre-cut strips
|
Veneer, PC, Unicolor
|
1 mm
|
|
Solid wood
|
Raw / polished / drawn
|
25 mm
|
