Description
Technical data
Max. suggested working thickness: 40 mm
| Model | Platen dimension (mm) |
Vertical thrust (ton) |
Side thrust (ton) |
Pressure bar ton) |
| gsl-a 25-13 | 2500 x1300 | 38,4 | 7,5 | 30 |
| gsl-a 30-13 | 3000 x 1300 | 57,6 | 9 | 30 |
| gsl-a 35-13 | 3500 x 1300 | 57,6 | 10,5 | 30 |
Max. suggested working thickness: 60 mm
| Model | Platen dimension (mm) |
Vertical thrust (ton) |
Side thrust (ton) |
Pressure bar ton) |
| gsl-a 25-13 | 2500 x1300 | 38,4 | 7,5 | 30 |
| gsl-a 30-13 | 3000 x 1300 | 80 | 24 | 30 |
| gsl-a 35-13 | 3500 x 1300 | 80 | 28 | 30 |
