Numerical Control Type Power Control
Software TOPDRILL BST 500

No. 2 Through-feed motorized conveyoring belts

No. 2 Horizontal units/supports (with Digital quota/axes display)
No. 1 Drilling head for each horizontal unit (1 x Kw 1,5)
No. 21 Splindles for each horizontal drilling head

Max. working width (mm) 2500
Min. working width (mm) 250

No. 4 Bottom vertical units/supports (with Digital quota/axes display)
No. 2 Drilling heads/blocks for each bottom vertical unit (2 x Kw 1,5)
N. 11 Spindles for each drilling head of the bottom vertical supports

No. 4 Vertical top pressure clamps
Motorized carpet to evacuate chips and wastes
Total installed power (Kw) 20
