Description

Sawblade Diameter 315mm

Sawblade Bore 30mm

Saw Projection – @ 900 @ 450

105mm 76mm

Spindle Speed 3700rpm

Table Size (l x w) 800 x 750mm

Distance Saw to Rip Fence 610mm

Fence with Micro Adjustment (lxw) 600 x 75mm

Dust Extraction Outlet Diameters 150 & 50mm

Total Air Volume Required 1445 CMH

VOLTAGE / FREQUENCY:

3 PH+EARTH; 400/230V 50/60 Hz

1 PH+N+EARTH; 230V – 50/60 Hz

MOTOR RATING 3 PH 3.0Kw IE2 (S1) ; 1 PH 3.0Kw

MOTOR FULL LOAD CURRENT IN AMPS 3 PHASE 6.5A ; 1 PHASE 18.7A

STARTING CURRENT IN AMPS 3 PHASE 39A ; 1 PHASE 70A

REQUIRED FUSE SIZE IN AMPS 3 PHASE 20A/ph ; 1 PHASE 40A

REQUIRED CABLE SIZE 3 PHASE 2.5mm ; 1 PHASE 4.0mm

Nett Weight 265Kg

Dimensions L x W x H 1500 x 1200 x 1200
