Description
Technical data
|
Machinable dimensions with lengthwise feeding
(length x width) (min/max)
|
min/max | 250×95 / 3000×1200 |
|
Machinable dimensions with crosswise feeding
(length x width) (min/max)
|
min/max | 120×250/ 1200×3000 |
| Operators | n° | 1 |
| Program change to Batch 1 (reading of unique code on panel by Bar Code / Qr Code) | – | NO |
| Possibility to size the panel | – | YES |
| Type, colour, thickness, edge protection film | – | YES |
| Panel dimension change | – | YES |
| Groove position and depth (in flexible mode) | – | NO |
| Glue dosage change | – | YES |
| Addition of a panel during Batch 1 machining | – | YES |
| Homogeneous panel management | – | YES |
| Closed loop management | – | YES |
| Panel re-machining | – | YES |
| Edge bander model | – | stefani xd / stefani s |
