Description
Technical data
x200 | x400 | ||||
Working areas | |||||
X-Y axes dimensions | mm | 2556×1296 3156×1596 3756×1596 3756×1896 3156×2216 4356×2216 |
|||
Axes | |||||
Vectorial speed X-Y axes | m/min | 84 (Pro-Space) 113 (Pro-Speed) |
|||
Z axis panel passage | mm | 150 | 180 | ||
Routing unit | |||||
Motor power (3-4 axes up to) | kW (hp) | 15 (20,5) | |||
Motor power (5-axis up to) | kW (hp) | – | 13,5 (18,4) | ||
Rotation speed (up to) | rpm | 24000 | |||
Available tools on tool changer (up to) | positions | 38 | 53 | ||
Drilling unit | |||||
Independent vertical spindles (up to) | n. | 21 | |||
Independent horizontal spindles (up to) | n. | 12 | |||
Rotation speed (up to) | rpm | 8000 | |||
Integrated blades | n. | 2 | |||
Integrated blade in X, diameter | mm | 125 | |||
0-90° blade unit | |||||
Motor power (up to) | kW (hp) | 2,2 (3) | |||
Rotation speed (up to) | rpm | 6000 | |||
Auxiliary routing unit | |||||
Motor power (up to) | kW (hp) | 5,4 (7,4) | |||
Rotation speed (up to) | rpm | 24000 |
