Double side – Independent Machine (or 1st and/or 2nd in a line)
Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3
Panels thickness (min/max) mm 12 / 40
Working width (min/max) mm 220 / 3000
Numerical Control PC 22 /Software WoodCommander
Adjustable feeding speed (m/min) 15 – 40
Safety and sound-proof enclosures/cabins – Adjustable working line (work units support tables)
Distance (center-axes) of the Disappearing Dogs (mm) 500
SIZING PART (for each side):
Spraying unit (Anti-sticking liquid)
Anti-chipping Milling Unit (1 x Kw 4,5)
Hogging Units KD 11 (2 x Kw 6,6) with Hydro-clamp
Free space
EDGE-BANDING PART (for each side):
Glueing Unit (Hot Melt Glue + Quick Melt system) A3 + A34
Edge coils support (No 24 reels) with servo-control edge feed + flex edge control software
Band Pressure zone (adjustable by N.C.) Type A – Height adjustment of the band by N.C.
Free space
Snipping (end-cutting) unit HL 86 (2 x kW 0,22) SERVO-motor, speed 35 m/min
Rough Trimming unit OPTIMAT Pneu (2 x kW 0,55)
Multi Function Unit (Profile contour Trimming unit) FK 21 (2 x kW 0,4) speed 30 cycles/min
Profile edge scraping unit (Multi-profile, adjustable by N.C.) MN 21
Finish processing unit (Glue scraper + Buffing unit) FA 11
