Angular sawing plant
Numerical Control Power Control + Software Cadmatic 4
Lifting table (mm) 3800 x 2200

1° Rear-pusher, with No. 4 clamps/grippers
Turning device (rotating unit) at 90°
1° Panel Saw – Max cutting width mm 3800
Max blade projection (mm) 95
Scoring Unit (max. diameter saw / power) mm 180 (Kw 2,2)
Main Sawing Unit (max. diameter saw / power) mm 380 ( Kw 18)
Adjustable speed of the saw carriage (m/min) 5 – 130 m/min

2°Rear-pusher, with No. 6 clamps/grippers
2° Panel Saw – Max cutting width mm 2200
Max blade projection (mm) 95
Scoring Unit (max. diameter saw / power) mm 180 (Kw 2,2)
Main Sawing Unit (max. diameter saw / power) mm 380 (Kw 18)
Adjustable speed of the saw carriage (m/min) 5 – 130 m/min

No. 2 Front supporting tables with Air blowing system (mm 650 x 2160)
Total power Kw 36 ca.

Stacking system of the cut panels – N° 1 x Liftomat HAU-A 25/16
OPTIONAL: Labels Printer
