Description
Description and features:
CONTROL SYSTEM
• Numerical control PC-based
• Software Biesse Works and BWIN
• Separated electrical cabinet
TECHNICAL FEATURES
• Useful working area (x – y – z) 4.850 x 1.535 x 250 mm
PANEL SUPPORT AREA
• Nr. 2 Working areas in “X” and nr. 4 locking independent zones in “Y”
• Nr. 8 Working tables EPS for supporting panels with automatic positioning – nr. 24 carriages
• Nr. 4 Lifting bars with pneumatic system
• Nr. 1 Vacuum pump 90 m³/h
BORING UNIT
• Nr. 1 Boring head BH 9
• Nr. 1 Multifunctional unit with aggregate with 3+3 horizontal overlapping outputs, pitch 22 mm 360° rotatable from NC
MILLING UNIT
• Nr. 1 Electrospindle 12 kW (16,1 HP) for horizontal milling, clamping system HSK F-63 air cooled complete with working unit device 360° with gears and right deflector
• Nr. 1 Multifunctional unit with blade aggregate diam. 270 mm 360° rotatable from NC
• Nr. 1 Predisposition for additional multifunctional unit
• Nr. 1 Chain tool changer with nr. 22 positions – center to center distance 180 mm
PREDISPOSITIONS AND ACCESSORIES
• Automatic lubrication system
• Chips conveyor
NORM AND OPTIONAL FOR SECURITY
• Copy of original EC Declaration of conformity
• Electronic frontal security mats
• Lateral protection grids
