Numerical Control Type NC 400 Deluxe
Through-feed motorized conveyoring belts (No.) 2

No. 2 Horizontal units/supports
Drilling heads for each horizontal unit (N°) 1
Splindles for each horizontal drilling head (N°) 20

Max. working width (mm) 3200
Min. working width (mm) 205 (ca.)

No. 5 Bottom vertical units/supports
Drilling heads/blocks for each bottom vertical unit (N°) 2

Vertical top pressure clamps (N°) 3
Transport belts to evacute chips (wastes) (N°) 2

Total installed power (Kw)

The CNC controls the movement (X axe) of the mobile horizontal unit
The CNC controls the movement (Y axe) of the stops
The CNC controls the movement (X axe) of the conveyor belts
