CONTROL SYSTEM
• Electronic control OSAI

TECHNICAL FEATURES
• Nr. 2 Working table: 1.600 x 1.600 mm
• Working area with joint working tables: 3.200 x 1.600 mm
• Vacuum pump of 250 m3/h

GROOVING/MILLING UNIT
• Nr. 1 Electrospindle clamping system HSK F-63 air cooled complete with working unit device 360°
• Nr. 1 Electrospindle clamping system HSK F-63 air cooled
• Nr. 1 Revolver tool changer magazine with 12 positions

BORING UNITS
Nr. 1 Drilling head completed of:
–       Nr. 8 Independent chucks for vertical drilling in “X”
–       Nr. 5 Independent chucks for vertical drilling in “Y”
–       Nr. 2 Independent chucks with double output for horizontal drilling in “X”
–       Nr. 1 Independent chucks with double output for horizontal drilling in “Y”

NORM AND OPTIONAL FOR SECURITY
• Copy of original EC Declaration of Conformity
• Frontal electronic security mats
• Lateral security fences
